PTS
The PTS printing and application machine offers the freedom to change configuration in just a few seconds, with interchangeable print heads, replaceable electronics on the fly, and a robust, compact structure.
The modular design accommodates 4", 5", or 6" (107/128/160mm) print heads, which can be swapped in seconds without replacing the entire system.
Thanks to its optimized design and modular chassis, PTS is more compact than any comparable machine: it is only 18mm wider than the 4-inch version of the Printess, but 37mm narrower than the 6-inch version. An ideal solution for any production line.
Autonomous printing unit with optional power supply and HMI.
Perfect integration into existing packaging machines and lines.
Foil rolls up to 1,200 meters for extended printing autonomy.
Labels up to 250mm in diameter, expandable to 350mm with high-capacity module.
Print Head: 107mm (4") / 128mm (5") / 160mm (6")
Print Area: Depends on the applicator pad
Print Resolution: 300dpi (12 dots/mm)
Label Size: Width up to 120mm – Length up to 500mm
Thermal Ribbon Roll: Width from 30 to 165mm – Max length 1200m
Label Roll: Max outer diameter 250mm for PTS, max 350mm for PTS-XT
Dimensions (without applicator): PTS 550 x 393 x 360mm - PTS-XT 655 x 393 x 360mm
