Mytho S
TECHNICAL SPECIFICATIONS
Control panel with 7" colour Touch display
Rotary turntable from Ø 1500 up to Ø 2450, depending on the maximum pallet size
Maximum load weight: 2000 kg
Column-only design
Maximum height reached by the top of the reel in the film carriage: 2450 mm
Turntable profile height: 75 mm
Automatic load height detection by photocell
Gradual and adjustable start/stop of rotation via inverter
Adjustable carriage up/down speed via inverter
Emergency/safety stop located at the base of the film carriage
Mushroom-head emergency stop button in compliance with CE standards
Machine reset button in compliance with CE standards
Acoustic signal at cycle start and at the end of the cycle
Flashing movement warning light
CYCLES SELECTABLE FROM THE CONTROL PANEL
F01 - 01 - Standard cycle (up and down)
F01 - 02 - Half cycle (up only or down only)
F01 - 03 - Complete cycle with additional bottom wraps at the same height as the starting position
F01 - 04 - Fast cycle (with little or no overlap)
F01 - 05 - Layer cycle
F01 - 06 - Economical cycle (to reduce the number of bottom wraps)
PARAMETERS ADJUSTABLE FROM THE CONTROL PANEL
Wrapping programs created by the operator. All functions can be selected directly from the display
Rotation speed adjustable from 5 to 12 rpm
Carriage up/down speed independently adjustable from 1.3 to 5.4 m/min
Bottom pallet wraps: 1 to 10
Top pallet wraps: 1 to 10
Intermediate reinforcement wraps
Pallet height photocell reading delay
Film tension adjustable for each phase of the wrapping cycle (for FE-PRS-PS carriages)
Variable film pre-stretch in each phase of the wrapping cycle (optional with PS carriage)
ACTIVATABLE FUNCTIONS
Keypad lock
Programmable wrapping start and end height
Pallet height wrapping by height sensor (photocell exclusion) – Sheet dispenser
Soft-start cycle
Step wrapping cycle with reinforcement and programmable number of wraps
Ergonomic Comfort height for film reel replacement
“FM” FILM CARRIAGE WITH MECHANICAL BRAKE
Mechanical brake on the idler roller with manual adjustment
Film reel Ø 250 mm with 76 mm internal diameter, h = 500 mm, maximum weight 20 kg
Alternatively, carriage with motorized pre-stretch system, type PRS (Power Roller Stretch), or type PS (Power Stretch).
Optional ARYA system for film attachment and cutting, including infrared remote control.
